Kuvaus
Polkupyörä Merida Big.Seven 15 2026 silk dark grey(black)
Bicycle technical specifications
Frame and suspension
Frame:
BIG.SEVEN TFS V; aluminium; 29; 135x9mm; BSA; Smooth welding
Fork:
SR Suntour XCE28; Coil; 100 STR; 27×2.25″ maximum wheel size
Drivetrain
Drivetrain groupset:
Shimano Tourney
Speeds:
14
Speeds:
2×7
Rear derailleur:
Shimano Tourney TY300
Front derailleur:
Shimano Altus FD-M315
Front shifter:
Shimano Altus EF-500-2L
Rear shifter:
Shimano Altus EF-500-7R
Crankset:
Prowheel TM-CY10; 36-22T; aluminium, Crank size: 165mm on all sizes
Cassette:
Shimano CS-HG210-7; 12-32T; 7-speed
Chain:
KMC Z7
Bottom bracket:
FSA TH-7420ST; 73-127.5mm
Pedals:
VP VPE-891
Brake system
Front brakes:
Shimano BR-M375; mechanical disc
Rear brakes:
Shimano BR-M375; mechanical disc
Brake discs:
Front: Shimano RT10; 160 mm, Rear: Shimano RT10; 160 mm
Cockpit
Handlebar:
MERIDA CC; aluminium; 15mm rise; XXS/XS: 700WHB; S: 720mm length
Stem:
MERIDA COMP CC; aluminium; 31.8mm handlebar center diameter; 7° angle, Length: 50mm
Grips:
MERIDA EC
Headset:
FSA NO.55R/57SC/57B, Compressor: FSA-TH-874-1, Spacers: 10mmx2
Wheels
Wheel size:
27.5
Rims:
MERIDA COMP CC; 20mm width; aluminium
Front hub:
Shimano TX505; 100x9mm; 32H; Centerlock
Rear hub:
Shimano TX505; 135x9mm; 32H; Centerlock
Front tire:
Kenda K1080; 27.5×2.2″
Rear tire:
Kenda K1080; 27.5×2.2″
Tubes:
27.5 x 2.2 A.V
Spokes:
Black steel
Saddle and components
Saddle:
MERIDA Sport
Seat post:
MERIDA COMP QR
Seat post clamp:
MERIDA CC; aluminium; 30.9mm diameter; 15mm setback
Accessories
Bell:
YWS-Alloy
Weight and dimensions
Weight:
14.5 kg
Maximum load (bicycle+cyclist):
120 kg
kokoXXS
